Compact Solution
Baby Padel Court
6m x 10m Compact Court
Perfect for limited spaces, the Baby Court offers all the professional features in a compact footprint. With no corner posts for maximum play area.
6m x 10m Compact Court
Perfect for limited spaces, the Baby Court offers all the professional features in a compact footprint. With no corner posts for maximum play area.
Discover what makes our Baby Court perfect for limited spaces
6m x 10m footprint perfect for limited spaces
Open design for maximum playing area
Lighting poles at 4 meters height
Complete specifications for Baby Court (6m x 10m)
155 x 60 x 2.5 mm bullet-shaped steel tube
133 x 40 x 2.5 mm trapezoidal steel tube
40 x 80 x 2.5 mm steel tube, 6 meters length
No corner posts (open design)
50 x 100 x 2.75 mm steel tubes, 10mm thick welded base flange, 8mm thick reinforcement ribs, 2 meters height
60 x 60 x 2.75 mm square steel tubes, lighting height 4 meters, cable entry holes maximized
4.0mm diameter steel wire mesh, 50 x 50mm mesh, laser welded to frame, frame main profiles: 100 x 50 x 2.0mm rectangular steel tubes + 3mm bent steel plates
920mm height, 80 x 80 x 3.0mm aluminum alloy, built-in pure copper rope tensioner, cast aluminum alloy post caps and crank, steel internal insert
3.0mm thick PE braided net, 45 x 45mm mesh, 6-mesh double-layer top, PVC mesh fabric with 6.0mm PVC-coated 304 stainless steel wire rope
Get in touch with our team to discuss your requirements and receive a personalized quote for the compact Baby Court.
